Appearance

SINGLE RESIN

INFINITE APPLICATION AREAS

WorléeSol E 150 W
Waterbased Acrylic & Alkyd Resins

The Solution for Sustainable Coating Systems

Worlée Products
DISPERMAT TORUSMILL

Innovative Dispersion Solutions

Dispersion Products
TQC Sheen

Ideal Finish Analysis

is in Turkish!

TQC Sheen Oven Tempature Data Logger
Corrosion Testing Units

Corrosion Testing Units

TQC Glossmeters

Single - Dual - Triple Angle Gloss Measurement

Pdf Datasheet User Manual Pdf Brochure Video

TQC SoloGloss, DuoGloss ve PolyGloss precision gloss meter for production and laboratory. Suitable for paint and coatings, plastics, automotive parts etc. Made in The Netherlands.

The TQC Glossmeter comes in three models. The Sologloss glossmeter measures 60°, the Duogloss glossmeter 20°/60° and the Polygloss glossmeter 20°/60°/85°. The 60º measuring angle can be used for any surface, from matte to glossy. For better gloss measurements on high gloss surfaces the 20° angle is available, while for low gloss surfaces the 85° angle suits best.

TQC Ideal Finish Analysis Software is included to analyze the gloss measurement results. This software provides the user the power to do all analysis of interest. Trend, Gaus and many other statistical evaluations are possible.

Precision-engineering

In order to get the best stability the TQC Glossmeter’s unique double hybrid frame system has been engineered with the highest precision. Carefully controlling the interior of the light patch helps to give the TQC Glossmeter robust and stable structure. The TQC Gloss meter is a solid well-engineered Dutch product.

Quality Guaranteed

To assess the quality of the TQC Glossmeter we took thousands of readings on certified substrates to test stability, reliability and durability. With or without shock testing the TQC Glossmeter proved to have the ultimate level of performance.

Features:

Easy to use
Using 20° geometry, measures high gloss surfaces like car refinishes, polished metals and plastics
Using 60° geometry, measures universal gloss for all king of surface finishes.
Using 85° geometry, measures matt finishes as Automotive interiors, decorative wall paints, wood etc.
"True Triple Angle Use" : Measurement and calibration simultanously at 20°,60° and 85°
Compatible with all important international standards
Memory for 2000 gloss readings (max 8 batches) and statistical analysis
With continious read option, multiple gloss measurements on large surfaces in seconds with average gloss determination.
Auto-ranging, Measures Matt to Mirror Finish
USB Output to download analyse and Store readings in Ideal Analysis Software
2 adet AA alkalin pil ile çalışır.
Extended two year warranty(in case of the device is licenced via Ideal Analysis software)
Accurate and reliable
Calibration gloss standard integrated in protective holder
Stable LED-light source

Order Id

Description

GL0010

TQC SoloGloss
60° Single Angle Glossmeter

GL0030

TQC PolyGloss
20-60-85° Triple Angle Glossmeter

RAL Color Charts

Standard RAL Colors

Pdf Brochure

The 4-digit RAL colours have been the standard for choosing colours for more than 70 years now. At the beginning the colour collection included 40 different colours. Its number has risen to 213 today.

The basic collection for matt colour shades is called RAL 840-HR, the one for glossy colour shades RAL 841-GL. Both basic collections contain colour samples that are being used by important institutions to cover a wide range of applications and are constantly adapted to the requirements of the industry. The registers are being used as colour samples for designs. They also contain safety- and signalling colours and fulfil the colour requirements of DIN regulations.

Order Id

Description

VF6600

RAL 840-HR
Primary standards of all 213 RAL CLASSIC colours
Semi matt
A5-sized (14.8 x 21 cm), colour illustration A6-sized (10.5 x 14.8 cm)

VF6601

Box for RAL Classic 840-HR color register

VF6602

RAL 840-HR, Single sheet, please specify colour

VF6603

RAL 841-GL
Primary standards of 196 RAL CLASSIC colours
High gloss
A5-sized (14.8 x 21 cm), colour illustration A6-sized (10.5 x 14.8 cm)

VF6604

Box for RAL Classic 841-GL color register

VF6605

RAL 841-GL, Single sheet, please specify colour

VF6606

RAL K7
Colour fan deck containing all 213 RAL CLASSIC colours
fan deck size 5.0 x 15.0 cm, colour illustration 2.0 x 5.0 cm
Five colours per page
Gloss

VF6607

RAL K5
Colour fan deck containing all 213 RAL CLASSIC colours
U-shaped protective cover
Full page colour illustration 5.0 x 15.0 cm
Well-suited for colour combination and colour comparison
Semi matt or gloss

VF6608

RAL K1
Booklet with 210 RAL CLASSIC colours
Booklet size 10.4 x 19.0 cm, colour illustration 1.8 x 2.8 cm
16 colours per page
Gloss

VF6609

RAL K6
Ring binder with all 213 RAL CLASSIC colours
A4-sized (21.0 x 29.7 cm)
All 213 RAL CLASSIC colours also available as single sheets
Semi matt

VF6610

RAL K6 single sheets, A4-sized (21.0 x 29.7 cm), please specify colour

VF6611

RAL F5
Information card with 210 RAL CLASSIC colours
Overall size 47.5 x 29.7 cm, folded 21.5 x 29.7 cm, colour illustration 1.2 x 2.2 cm
All colours at a glance
Gloss

EasyQC - Mix2Match

Color Measuring & Matching

NS800/NS810 Spectrophotometer

NS800/810 brings together the new cost effective technologies with the hi-end spectrophotometers. NS800/NS810 can measure the color and density of the various painted or printed surfaces like paper, textile, or metal. Xenon daylight flash of the device enables you to measure floureacence exactly as you observe in real daylight.

EasyQC®

Easy-QC is a quality control software which can be connected to most of the color measurement instruments available. It works under Windows® from Microsoft® using its flexibility for the presentation of results and makes it easy to use.

Colorimetric Norms

It uses all norms available to determine color difference systems « Lab, LabCh 76, 94 and 2000, CMC, LabHunter, CIELuv, CIELuvCh, UCSCIE-64, CIEXYZ, FMCII, CIEYxy, NBS », light sources « A, B, C, D50, D65, D75, F, F2, F6, F7, F8, F10, F11, F12, W »and observers « 2° & 10° ».

Mix2Match®

In addition to EasyQC quality control software's all capibilities, Mix2Match is a advanced computer aided color matching software which enables easy color formulation. After characterisation of the pigments or pastes, the standard color which measured by SpectroCam, formulation can be easily calculated using your own raw materials.

Order Id

Description

CCM-NS800

Spectrophotometer NS800, 45/0°, 8mm aperture

CCM-NS810

Spectrophotometer NS810, D/8 Sphere, 8mm aperture

CCM-ROS1

X-rite i1 Basic Pro2 + EasyQC Color Quality Control Software

CCM-ROS2

Spectrophotometer Spectroguide 45/0

CCM-ROS3

NS800 Spectrophotometer + EasyQC Color Quality Control Software

CCM-ROS4

X-rite i1-Pro + Mix2Match Color Formulation Software

CCM-ROS5

NS810 Spectrophotometer + Mix2Match Color Formulation Software

CCM-ROS6

Mix2Match Color Formulation Software

TQC ColorBox

Light Cabinet for Color Inspection

Pdf Datasheet User Manual Video

TQC Colorboxes offer a extensive range of illumination conditions for any visual inspection. The multiple selectable light sources allow assessment of gloss, structure, damages and metamerism.

The Colorboxes are available in 60 and 120cm width. All are supplied with removable viewing table and runtime counter. Both interior and exterior are finished to the highest quality standard. The ability to switch between light sources without flickering makes the cabinet extremely stable. TQC Colorboxes are equipped with a 110 / 220 V switch.

Order Id

Description

VF0600

TQC Colorbox illuminated assessment cabinet, 60cm + 45°sample table
Light sources:
light bulb type "A" 40 W E 27
light tube "shop light" TL84 (F11) 60cm
light tube "day light" D65, 60 cm
light tube "day light" D5000 (D50) 60cm
light tube "black light" UV 60cm

VF1200

TQC Colorbox illuminated assessment cabinet, 120cm + 45°table
Light sources:
light bulb type "A" 40 W E 27
light tube "shop light" TL84 (F11) 120cm
light tube "day light" D65, 120 cm
light tube "day light" D5000 (D50) 120cm
light tube "black light" UV 120 cm
